1298 Wharram Tiki 46


Currently Belgian flagged.

Email Scott Brown

  • General +

    Wharram Tiki 46 #25 - sold by it's builders and unique owners.
    Built from top quality Bruinzeel Hechthout Lloyds approved plywood and West System epoxy.
    Hulls and beams as per plans.
    Many modifications to make the cruising life of a couple more comfortable.
    Two side by side masts with junk sails for smooth and easy handling.
    Electric propulsion for excellent maneuvering en plenty of 230V power on board.
    Launched in 2009 and extensively sailed with 15,000 nautical miles, including two Atlantic crossings.
    Reliable, proven concept of junk sails and electric propulsion.
    Very well maintained and multiple enhancements.
    Well documented : building, tuning and cruising phases, cabling, and user's guide with all specific topics to the craft.
    Currently under light refit after the Atlantic crossings. Sold ready to start a new sailing season in the Mediterranean.
  • Hulls & decks etc +

    We organized APATIKI to accommodate a couple in comfort in hot climates, six months per year in the Mediterranean and full-time in areas like the Canary islands or the Caribbean.
    We decided on purpose to keep the furniture as basic and functional as possible in the pure Wharram spirit. It means no door frames in bent hardwood, no shiny worktops, no glossy bulkheads, no laminate teak flooring but simple plywood coated in white or with clear epoxy.
    The cockpit bubble offers with its clear vinyl windows good visibility and wind or sprays protection. The white tarpaulins are efficient for shade and good ventilation.
    We use the cockpit as the center of life of APATIKI.
    The doghouse with its sitting headroom is the other center of life when sailing shorthanded in rough weather conditions.
    It includes the galley with a Wallas Diesel stove and heater lid, a microwave oven, a Waceo / Dometic 50 liters fridge (2014), a sink with pressurized water tap, a single bunk and a porta-potti portable toilet hidden under a seat.
    The starboard hull offers a huge “master cabin” with a bathroom aft.
    The port hull comes with a home office, a multipurpose workbench area, and a double guest cabin aft.
    There is fore of each hull a storage area with shelves and separated from the cabins by a watertight bulkhead.
    Note : the home-office could be easily transformed into the classical U shaped saloon that can also be used as an extra double bunk.
    There is already a cabinet in front of the multipurpose workbench that was originally built to accommodate a combined sink/stove unit.
    The hulls are insulated with 20 mm cork in the cabins to reduce heat, noise and vibrations.
    A total of 15 wall mount halogen cabin lights.
    There are on deck 12 Lewmar Ocean hatches and 6 Plastimo dorades for light, ventilation and water tightness. Also 2 Lewmar escape hatches.
    The antifouling consists in 4 layers of Coppercoat for low maintenance (2012).
  • Rig & Rigging +

    Based on Sunbird '90s design by Alan Boswell
    2 x sail made of 8273 style 270 gr/m² cream fabric by Chris Scanes
    Initially 55 m² each in 7 panels reduced to 6 panels (approx. 50 m²)
    2 x sail cover
    2 x mast : 6 mm aluminum tubes with pinned sleeves.
    Many modifications and enhancements to meet ocean crossing requirements
  • Engines +

    Electric propulsion sold, installed and maintained by idtechnology.nl
    The same motors are also sold by Mastervolt agents worldwide.
    2 x 10 Kw Aquamot electric motor
    2 x 200 Ah 48V AGM battery bank (starboard one replaced in 2013)
    1 x 8 Kw 230V 1500 RPM 51 dB (A) water cooled LMG 8500 Lombardini generator on deck
    4 x Piktronik 18 Ah 48V programmable battery charger
    2 x Piktronik board computer, controller and joystick
    1 x 110 Ah AB Power lead-acid generator start battery
    We are sailors and we avoid as much as possible to use the motors.
    Our philosophy : no fixed planning, no agenda, no predefined itinerary, no mandatory appointment, no flight to catch. We go where and when the wind allows us to sail !
    The electric motors reflect this sailing attitude. We configured them to meet the following requirements :
     maneuvering in safety, comfort and silence in marinas and anchorages,
     1 hour full throttle in case of emergency (top speed above 7 knots in good conditions),
     100 nautical miles in 24 H in case of flat calm (no wind, no swell, no current).
    Fuel consumption at 4 knots : less than 2 liters per hour
    Fixed fuel tanks : 65 L and 45 L = 110 L
    Portable PVC fuel tanks : 9 x 20 L = 180 L
    Total mileage : 290 L = 145 H = 580 NM @ 4 knots in flat calm
    This configuration could be reviewed to meet other requirements by adjusting the number of batteries / battery chargers and installing a more powerful generator.
  • Steering and Navigation +

    Raymarine Smart Pilot X-5 wheel
    Pacific Windpilot
    Panasonic CF-19 Toughbook portable PC / tablet
    ShipModul NMEA – Bluetooth multiplexer
    Tacktick GPS
    Tacktick dual display
    Raymarine i40 wind system with Rotavecta transducer (2014)
    Raymarine ST40 Depth with Low Profile transducer
    Comar AIS-2-NMEA receiver
    Oxygen audio MP204 FM-CD-MP3 radio
    2 x Osculati OS-612B 100 W water resistant 2 way speakers
  • Comms and Security +

    Cobra Marine MR F80EU VHF (2013)
    ACR RLB-36 GlobalFIX IPRO 406 MHZ GPS EPIRB (2013)
    Iridium 9505 satellite phone with data kit (2002)
    1 x Sea-Safe 8 person auto-righting inflatable life raft
    2 x grab bag
    1 x flare kit
    1 x pharmacy
    3 x 6 kg fire extinguisher
    2 x 2 kg fire extinguisher
    2 x Spinlock Deckvest 5D (2013)
    4 x Osculati 150N inflatable lifejackets
    1 x Petzl Navaho Bod Croll Fast harness
  • Electrical ~ 12V +

    12 x 30 W Victron solar panel (total 360 W)
    2 x Victron 40 A BlueSolar MPPT
    2 x Victron Centaur 40 A battery charger
    3 x Victron BMV-600 battery monitor
    3 x Victron 110 Ah Gel battery (total 330 Ah) for house battery bank
    3 x Victron 90 Ah AGM battery (total 270 Ah) for windlass
    1 x Studer 400 W 230 V – 12 V sine wave inverter
  • Ground tackle etc +

    Lofrans Tigres 1200 W windlass
    MZElectronics chain counter
    100 m of 10 mm chain
    1 x 35 m of 10 mm chain and 1 x 35 m of 20 mm nylon
    2 x Delta 20 kg anchor
    1 x Brittany like 10 kg anchor
    100 m of 20 mm nylon cut in multiple mooring lines
    8 x Polyform US A3 fender
    2 x Polyform US A5 fender
  • Water & Toilets +

    Katadyn PowerSurvivor 160 E 25 LPH watermaker with additional prefilter and boost pump
    100 L water tank in starboard bilge
    5 x 20 L portable water tanks
    Whale Universal UF0813 pressure pump 3 bar 8 LPM
    Elgena 10 L 12 V 200 W boiler
    1 x deck shower
    1 x washbasin 1 tap and 1 shower in bathroom
    1 x sink and 1 tap in doghouse
    3 x porta potti portable toilets
  • Dinghy +

    Imnasa 2.5 m inflatable dinghy with hard bottom (still OK but the color has faded due to UV’s)
    Suzuki DF 6 four stroke outboard
  • Planned Refit +

    Included in the sales price
    A REFIT to get APATIKI in the same conditions (or even in better conditions) than when we left Turkey in April 2013.
    NB. Ask Scott Brown for details.
