1311 Wharram Tiki 31 in Med

SOLD

Currently Austrian flagged. Possibly the best ever...

Email Scott Brown

  • General +

    Wharram Catamaran Tiki 31
    Designed by James Wharram & Hanneke Boon
    Self-builder-plans No. 64
    Built in Styria/Austria from 1991 to 2000
    Launched on 25.08.2000
    The catamaran is certainly one of the most beautiful Tiki 31.
    Currently Austrian flagged, lying near Lignano/Italy.
    The boat is well maintained and equipped, has many extra features and is ready to sail.
  • Tiki31 data +

    LOA Length overall: 9,85 m
    Length of hulls: 9,52 m
    LWL Length waterline: 8,23 m
    Beam overall: 5,33 m
    Beam of each hull: 1,47 m
    Draft: 0,53 m
    Weight (empty) as per plan: 1.360 kg
    Carrying Capacity: 1.000 kg
    Sail area working rig: 36,2 m2
    Rig: Gaff Wingsail
  • Hulls & decks etc +

    Plywood: 8mm + 10mm Okoume
    Timber for hulls: Sitka-Spruce
    Timber for beams and deck: Yellow-Pine
    Hardwood: Sapelli-Mahagoni
  • Rig & Rigging +

    Aluminium Masts and Stainless steel Standing rig
    from Imagine Multihulls, England
  • Sails +

    Terylene (Dacron) from Jeckels Sails, Wroxham, England
    Main 15,05 m2
    Mizzen 13,00 m2
    Jib 8,20 m2
    Mizzenstaysail 13,20 m2
    Mizzenstaysail or 2. Jib 8,20 m2
  • Engine +

    Yamaha F9.9AEL 9,9hp 4-stroke Outboard
    Code 6G8/L, Nr. 466999, appr. 250 Engine hours
  • Electronics & Nav +

    Compass: SILVA 125 F
    Log: Nasa Clipper
    Echo-sounder: Nasa Clipper
    Wind: Nasa Clipper
    Autopilot: Autohelm ST3000
    GPS: Furuno GP-31
    VHF: Nasa SX 35 DSC
  • Ground tackle etc +

    "Bügel"-anchor 16 kg 50 m chain 8 mm
    "Stock"-anchor 25 kg
    Anchor winch Anchorman Manual
  • Safety Gear +

    Solid life jackets
    life ring
    anchor light, etc.
  • Galley +

    Origo 3000 Alcohol stove 2 burners
    crockery
  • Toilet & washing +

    Lavac Vakuum toilet
    Washbasin with foot pump
    Blake seacocks
  • Dinghy +

    Inflatable Z-RAI IV (already repaired, but still O.K.)
  • Misc +

    7 fenders
    battery charger Mobitronic
    mooring ropes
    div. tools
    div. spare parts
    shackles and roles
    manuals, charts, navigational equipment, nautical literature
    cover net, etc.
  • Extra info +

    Building time until launching: 4.200 hours
    of that:
    for the boat according to plan approx.: 2.500 hours<
    for additional work approx.: 1.500 hours
    Assembly: 200 hours
    NB. Note the current canvas colour is Navy Blue, some photos show the previous White canvas.
