1455 Tiki 38 in France
|
Deposit Received German built. |
|
-
General +
Wharram Tiki 38, 5 years since completed.
Everything built 1:1 according to plan -
Hulls and decks +
All material installed according to plan:
-WEST System Epoxy
-Epifanes 2K varnish
-Hempel antifouling
-19x Geba sea windows (can be opened)
-Hatches with magnetic catch and neoprene seal -
Rig and Rigging +
-Wooden masts according to plan
-Colligo marine blocks
-Dynema 10mm rigged -
Sails +
The sails are made by Jeckells on the recommendation of James Wharram
-2x main sail
-jib
-storm jib
-spinnaker
The main sails are sewn for outboard running halyards. -
Engines +
2x Yamaha outboards with extra long shaft.
-Model FT9.9G
-Have tiller steering fixed at Yamaha Service
-Approx. 200 hours operating time
-4x 25 litre original Yamaha tanks
-Water separator for petrol -
Ground Tackle +
-Rocna 20kg
Extra rocna 15kg and chain
-40m anchor chain
-50m anchor rope
-Kong swivel -
Electrics/Navigation +
-Victron BMV battery monitoring system
-2x TX solar modules with 255 Wp output each.
The modules are equipped with 5m cable and can always be optimally positioned in relation to the sun.
-2x VOTRONIC solar controller MPP 165
-Philippi switch panels
-2x Sterling Power Pro Charge Ultra chargers 12V - 20
-2x Trojan 120A deep-cycle traction batteries (can be discharged to 20% capacity, i.e. 100A before recharging is required)
-Raymarine Lighthouse Element 7 HV Plotter
-Easy TRX AIS Class B SOTDMA
-VHF Furuno RO 4800 with handheld radio and external loudspeaker
-Iridium Go satelite receiver, for whether routing with predict wind, e-mail etc.
-VHF Furuno RO 4800 with handheld radio and external loudspeaker. **Mast cable needs to be replaced but there's an extra antenna that can be used on deck.**
-Floating Marine Transceiver HX210 (3 year waterproof warranty)
-New Starlink mini 3.0
=Long shore power cable -
Safety +
-AIS
-DSC
-EPIRB
-Lifeline
-Fire extinguisher 2kg in each cabin
-First Aid Kit
-4 Secumar inflatable lifejackets
-1 Besto life-ring -
Galley & Plumbing +
-ENO cooker with 3 burners
-SMEV Oven Mod. OF300
-2x 5kg gas cylinders with adapters for filling
-2 sinks
-Cool box as in the plan approx. 70-80 litres, with WAECO water-cooled unit 50W with cold accumulator (does not need to run at night)
-all onboard outlets and valves from TRUEDESIGN (plastic/GRP).
Reinforced side wall at the inlets below the waterline
-Whale hand pump is connected to a 20 litre canister -
Heads +
-LAVAC with hand pump **(bilge pump integrated)**
-50 litre holding tank with suction connection
-small washbasin
-10 litre shower (like garden sprayer) -
Dinghy +
-Achilles (made in Japan ) 2,45m Hypalon Dinghy
-Yamaha 4PS Outboard -
Misc 1 +
-Water maker ex14-12 from H2O Factory, 50W power consumption 50W at 12 litres of water per hour. Standard industrial membrane modules 470mm-480mm
-Superwind 350 wind generator
-Hebridian Wind Vane wind self steering system (still to be adjusted)
Fenders:
-4 long fenders
-2 ball fenders
-4 smaller long fenders
-Many maintenance tools and spare parts (Sewing kit for sails, Splicing kit
-Various kitchen utensils, Binocular, Windmaster, Extra dyneema ropes etc) -
Misc 2 +
-KIWI Grip Antislip on deck
-Gisa Med mattresses
-Hygrometer, Barometer & Clock -
Owner Comment +
The boat is now in Paimpol, France.
It had a full survey report done in December 2024 by Rory Mcdougal.
The natural woodwork was been treated and both masts were overhauled and painted with PU varnish in july 2025
